FEATURE & FUNCTIONS

Oceanic VTX Specifications

What’s in the Box

VTX Air integrated dive computer, Wireless transmitter (VTX Transmitter Combo Only), Lens protector, Dive computer resources DVD, (Operating Manuals, PC Interface Software, USB Drivers), High-density wrist strap,
2 extra CR2 batteries, Safety and reference manual, Data transfer
cable, Protective carrying case

Computer Type

Hoseless Air Integrated Color OLED Display w/bluetooth

Interface

Menu

Modes of Operation

Norm (Air & Nitrox), Gauge, Free Dive

Push Buttons

3

Digital Compass

3-Axis / Full Tilt

Nitrox Mixes

4 (21 – 100%)

Algorithm Basis

Powered by Dual Algorithm¨ allowing you to choose the decompression algorithm that best suits your diving needs without compromising safety. Choice between Pelagic DSAT* (Spencer/Powell data basis) or Pelagic Z+ (Buhlman ZHL-16C data basis)

Algorithm Reset

Desaturation

Conservative Factor

On / Off

Altitude Algorithm Basis

NOAA

O2 Limit Basis

NOAA

Tissue Compartments

12 (5 to 480 minutes)

Automatic Altitude Adjustment

2,000 – 14,000 ft / 610-4200 m

Decompression Capability

10 – 60 ft (3-18 m)

Automatic Safety Stop Prompt

YES

Cylinder Pressure and Air Time Remaining

YES

Audible Alarm

YES

Alarm Acknowledgment (U/W Deactivation)

YES

Ascent Rate Range

3-9 m/min – 6-18 m/min

Ascent Rate Maximum

30 fpm – 9 m/min

Backlight

Adjustable Intensity & Auto Dim Percentage & Time

Visual Alarm

Color Coded Information:

Amber = Warning; Red = Alarm

Battery Type

Diver Replaceable.

Wrist Unit: (1) 3v CR2

Transmitter: (1) 3v CR2

Battery Life*

Wrist Unit: 15 dive hours at 100% Brightness with Auto Dim set OFF. 34 hours at 60%.

Transmitter: 1500 hours

Low Battery Indicator (Graphic)

YES

Calendar / Clock

YES

Operating Depth (Max)

330 ft (100 m)

Operating Depth (Gauge Mode)

330 ft (100 m)

12/24 Hour Time to Fly Countdown

YES

Calculated Desaturation Countdown

YES

High O2 Alarm / Warning

300 SOTU / DOTU

High PO2 Alarm / Warning

1.6 DEFAULT OR USER SETTING

On-Unit Log Capacity

24 Dives

OceanLog PC Download

OPTIONAL

OceanLog PC Settings Upload

OPTIONAL

OceanLog Download Memory Capacity

UP TO 150 DIVES**

Pre-Dive Planning Sequence

PUSH BUTTON 30-190 ft / 9-57 m

On-Unit Simulator and Dive Planner

NO

Temperature Display

YES

User Reset / Power Off

YES

Air Time Remaining Bar Graph

YES

Nitrogen Tissue Loading Bar Graph

YES

Oxygen Loading Bar Graph

YES

Variable Ascent Rate Bar Graph

YES

No Decompression Time Remaining Display

YES

Air Time Remaining Display

YES

O2 Time Remaining Display

YES

Set Mode with Rapid Advance

YES

Set "Turn Around" Pressure Alarm

YES

Set "Ending" Pressure Alarm

YES

Set FO2 Value (%)

AIR, 21-100%

Set Audible Alarm On/Off

YES

Set Max Depth Alarm

YES

Set Elapsed Dive Time Alarm

YES

Set Maximum Nitrogen Tissue Loading Bar Graph Alarm

YES

Set Dive Time Remaining Alarm

YES

Set Units Of Measurement

YES

Set Time Format (12/24 Hour)

YES

Set Time of Day

YES

Set Date

YES

Set Maximum PO2 Alarm

YES

Set Backlight Duration

YES

Set Sampling Rate (OceanLog Download)

Norm / Gauge: 2/15/30/60

Free Dive: 1

Set Digital Gauge Mode On/Off

YES

Set Water Activation On/Off

YES

Warranty

2 YEARS
